LITTEL MULTI-SWITCH – ACCESSORIES
PHONE: 773 792-2700
308
SWITCHES
?
* Please visit the product pages on our website for the most up-to-date product information
MULTIPLE-STATION SWITCHES (continued)
LITTEL ? MULTI-SWITCH ACCESSORIES
WIRE-WRAPPING TERMINALS
RECOMMENDED WIRE-WRAPPING TOOLS
Special order wire-wrapping terminals optimize use of
semi-automated termination equipment to save production
line time. Terminal shoulders accommodate 1, 2 or 3 wrapped
Wire Gauge
(Gardner -Denver Co. Part Numbers)
Wrapping Bit Sleeve
connections per terminal and prevent wrapping tool from
“bottoming” (on first wrapped connection) and possibly
shorting against other metal parts on switch stack. 4-C
#22 & #24
#25
#26
500131
500131
37006
18840
18840
17611-2
switching per station maximum.
NOTE: Stack height dimension will be greater when
RECOMMENDED WIRE-WRAPPING PARAMETERS
wire-wrapping terminals are specified. Stack height for 1-A
Wire
Number of
Wraps Per
Wire
Number of
Wraps Per
and 1-B circuit is .516" (13.11 mm). For 1-C height is .594"
Gauge
Connections
Connection
Gauge
Connections Connection
(15.09 mm).
ORDERING: Contact Switchcraft for details.
#22
#24
3
3
4
5
#25
#26
3
3
4
5
SHOULDER
SERIES 37000
WITH WIRE- WRAPPED
TERMINALS
LAMP SOCKETS AND ADAPTERS
LAMP SOCKET T10 ?
Standard on Series 37000, T10 accepts standard midget
flange type T1-3/4 lamps.
LAMP SOCKET T12 ?
LAMP SOCKET T12
LAMP ADAPTER T1
SERIES 35000 WITH
WIRE- WRAP* TERMINALS
* Registered trademark of Gardner-Denver Co.
Standard on Series 38000, the T12 socket accepts standard
midget flange type T1-3/4 lamps.
LAMP ADAPTER T1
Converts sockets that accommodate standard T 1-3/4,
(P1593) midget flange base lamps to accept T 1 subminiature
lamps. Adapter fits T 1-3/4 lamp socket. The 2-piece adapter
holds lamp securely in place to assure positive contact of
lamp circuit in most environments. If you require extra
long-life, specify a T 1 lamp adapter for each T 1-3/4 socket.
PC TERMINALS
Copper alloy PC terminals are integral with associated leaf
spring and feature shoulders for proper clearance from PC
board and for solid mounting. Contact Switchcraft for details.
? Available on special order only; Contact factory for price and delivery information.
SERIES 37000 WITH PC TERMINALS
DIMENSIONS ARE FOR REFERENCE ONLY
www.switchcraft.com
Inch
(mm)
? Registered trademark of Switchcraft, Inc.
Note: Contact your Switchcraft Representative for price and delivery
